General Pump Car Wash Series Left Shaft Plunger Pump - 5 GPM, 3000 PSI, 1/2 IN X 3/8 OUT Part Number CW3040L

The General Pump CW3040L Plunger Pump has a large-capacity aluminum crankcase, a forged brass manifold, and solid ceramic plungers. A preferred pump frame in the pressure cleaning industry, this pump is excellent for commercial car wash applications.

• 5 GPM flow rate

• 3000 PSI maximum discharge pressure

• 1/2" BSP-F inlet port thread

• 3/8" BSP-F discharge port thread

• 1250 RPM maximum pump speed

• 125 PSI maximum inlet pressure

• 9' water maximum inlet vacuum

• 20 mm bore

• 16 mm stroke

• 24 mm solid shaft - left mount

• 40.6 ounce crankcase oil capacity

• 165° Fahrenheit maximum fluid temperature

• Weight: 32 lbs.

Features:

• Forged brass manifold with an exclusive lifetime warranty

• Large-capacity, die-cast, anodized aluminum oil-bath crankcase

• Oversized connecting rods for maximum life

• Heavy-duty tapered roller bearing

• Solid ceramic plungers with continuously lubricated packings

• Unitized stainless steel inlet and discharge valves

• Available in a right-hand shaft version (part #CW3040)
