Giant Pumps Stainless Steel Pulsation Dampener, 13 GPM, 1/2 In. MNPT Part Number 22050A-5100

Pump Vibration Dampener

The Giant 22050A-5100 Pulsation Dampener is a device used with positive displacement pumps to reduce vibration and pulsation during operation. This dampener contains a rubber bladder that is precharged with nitrogen up to 50-60% of the system pressure. This vibration dampener is used to protect equipment and piping in a high-pressure system. Has a rebuildable design for easy service.

• Flow Rate: 13 GPM (49 L/min)
• Maximum Pressure: 3000 PSI (207 bar)
• Pressure Maximum Charge: 1500 PSI (103 bar)
• Maximum Continuous Temperature: 200° Fahrenheit
• Inlet: 1/2" MNPT
• Weight: 5.2 lbs. (2.4 kg)
• 316 stainless steel construction
• Rebuildable design
